The Stainless Steel Solenoid Valve is a control element that uses an electromagnetic drive to achieve automatic opening and closing. It is mainly used for fluid on-off and regulation in liquid or gas medium pipelines.
Advantage
Corrosion resistance
The Stainless Steel Solenoid Valve is made of 304 or 316 stainless steel. In a salt spray environment, 304 stainless steel can last 480 hours without red rust, and 316 stainless steel can last 720 hours. It is particularly suitable for corrosive media environments such as chemicals, seawater, acid, and alkali, ensuring long-term stable operation of the equipment.
Reliable sealing
The solenoid valve has built-in PTFE and EPDM high-performance seals, which can automatically adapt according to the medium temperature and pressure. Even in high-temperature and high-pressure environments, the leakage rate remains below 0.01%, effectively preventing medium leakage.
Quick response
Stainless Steel Solenoid Valve is equipped with a highly sensitive coil system, with a power-on response time of less than 50 milliseconds and a closing time of no more than 200 milliseconds, meeting the needs of high-frequency opening and closing occasions.
Low failure rate
Stainless Steel Solenoid Valve uses high-strength engineering plastic components combined with stainless steel fasteners, with a mean time between failures of more than 10,000 hours, effectively reducing downtime and repair costs.
Technical data
|
Power supply voltage |
AC24V, AC36V, AC127V, AC220V, AC380V, DC12V, DC24V, DC36V, DC72V, DC110V, DC220V, |
|
Protection type |
ordinary type, waterproof type, explosion-proof type |
|
Pressure range |
0-0.3MPa (no differential pressure), 0-0.6MPa (no differential pressure), 0.03-0.6MPa, 0.03-1.6MPa, 0.03-2.5MPa, 0.03-4.0MPa, 0.03-6.3MPa |
|
Medium temperature |
0-200C, 0-250C, |
|
Ambient temperature |
-10-40C, -20-40C, -40-40C, -10-60C |
|
Connection |
internal thread connection, flange connection, according to the requirements of the working conditions, but the diameter exceeds DN50, all are flange connections. |
|
Body Material |
Ductile Iron, Cast Steel, 304 Stainless Steel, 316 Stainless Steel |
